Vector Addition

Vector Additionvideo

Vector addition

What is vector addition?

• Adding vectors together lets us describes the movement between two points

• To add or subtract vectors numerically simply add or subtract each of the corresponding components

• In column vector notation just add the top, middle and bottom parts together

  • For example: $\left(\genfrac{}{}{0pt}{}{2}{1}\right)-\left(\genfrac{}{}{0pt}{}{1}{4}\right)= \left(\genfrac{}{}{0pt}{}{1}{-3}\right)$

• In base vector notation add each of the i and j components together separately

  • For example: (2i + j) – (i + 4j) = (i – 3j)

• Adding vectors creates a single vector which is called the resultant vector

  • The resultant vector will be the shortest route from the start of the first vector to the end of the second

• Subtracting a vector is the same as adding a negative vector

• Adding the vectors PQ and QP gives the zero vector, denoted by a bold zero 0 (0 in handwriting)

What are scalars and parallel vectors?

• Two vectors are parallel if and only if one is a scalar multiple of the other

  • i.e both components of the vector have been multiplied by the same constant

• Multiplying a vector by a positive scalar changes the magnitude (size) but not its direction

• Multiplying a vector by a negative scalar changes the magnitude and the direction would be reversed

How do I find the vector between two points?

• If, relative to the origin $O$, the points $A$ and $B$ have position vectors

  • $\overrightarrow{OA}=\mathbf{a}$

  • $\overrightarrow{OB}=\mathbf{b}$

then

• $\overrightarrow{AB}=\overrightarrow{AO}+\overrightarrow{OB}=-\overrightarrow{OA}+\overrightarrow{OB}=-\mathbf{a}+\mathbf{b}=\mathbf{b}-\mathbf{a}$

• Similarly, $\overrightarrow{BA}=\overrightarrow{BO}+\overrightarrow{OA}=\mathrm{a}-\mathrm{b}$

• This result is particularly useful when working with position vectors (as the 'journey' can always go via the origin)

  • but the result applies to any set of three vectors
